-Realization of High Precision Machining
-Realization of Low Noise
-Implementation of Convenient Operation
-The change of mode height is small, the deviation of kinetic energy center is small
-Mould life greatly increased
-Minimum Deformation in Stamping
-Low cutting noise
-Low integrated clearance
-Servo motor modulating to improve the modulating convenience
Model |
GT30T |
GT40T |
GT60T |
GT80T |
Capacity |
Ton |
30 |
40 |
60 |
80 |
Stroke length |
mm |
20/25/32 |
16/20/25/30 |
20/25/32 |
20/25/32/36 |
Stroke per minute |
s.p.m |
1200/1050/900 |
1200/1100/1000/950 |
750/650/600 |
700/600/550/500 |
Minimum number of trips |
s.p.m |
180 |
180 |
180 |
180 |
Die height |
mm |
240 |
240 |
300 |
320 |
Slide Adjustment |
mm |
40 |
50 |
80 |
80 |
Slide area |
mm |
600X300 |
750×340 |
1030×500 |
1080×580 |
Bolster area |
mm |
600X400 |
750×500 |
1100×600 |
1200×800 |
Bolster thickness |
mm |
90 |
120 |
140 |
160 |
Main motor |
kw |
11 |
15 |
22 |
30 |
JIS accuracy |
|
特级 |
特级 |
特级 |
特级 |
Gross weight |
kg |
约6500 |
约8000 |
约14000 |
约19000 |
Standard accessories |
Optional accessories |
Inverter+Variable apeed moter |
|
Combination type air friction clutch/brake |
|
Dynamic balancer(weight fixed type) |
|
Electronic rotary cam switch |
|
Stop position control unit |
|
Electronic crank angle indicator |
|
Human machine interface |
Air ejector(with solenoid valve) |
Speed meter |
Materials oiled wheel |
Total counter(9-digit) |
Flywheel brake |
Preset counter(9-digit) |
Stock holding cylinder |
Closed mold height display device |
Bottom dead point detector |
Hour meter(7-digit) |
Safety door(Pneumatic) |
Servo Slide Adjustment device |
Misfeed detection unit |
Misfeed interface(With sweitching function) |
Cutting detection unit |
Over-tension stop outlet 1pc |
Gripper cam feeder |
220V outlet(10A)1 pc |
Stock guide |
380V outlet(10A)1 pc |
Quick die change system and accessory equipments |
Micro inching(reverse avaliable) |
|
Criculation type lubrication unit |
|
Pneumatic control unit |
|
Air outlet(1/4B) |
|
Stock oil tank(with solenoid valve) |
|
Safety door(Manual) |
|
Stock end stop switch(proximity) |
|
Working light |
|
Motor reverse device |
|
All stop circuit |
|
Selfstand type poeration box |
|
Both hands push buttons |
|
Shock absorber |
|
Oil heater/cooler |
|
